Specifications
| Measuring range | A档：(20~500)J/m²；B档：(500~1000)J/m² |
| impact angle | 90° |
| resolution | 0.1J/m2 |
| Error of indication | A档：±1J/m²；B档：±2J/m² |
| sensor | SH30-5000-2V |
| Specimen size | 25.4*25.4mm |
| Sample holding force | 0~40Kg/cm2 (adjustable) |
| unit | J/m2、lbf/in2 interchange |
| interface | Touch screen control |
| Modular integrated thermal printer | |
| Power | AC220V ± 22V, 50Hz, maximum current 3A, the Power should be reliably grounded |
| Weight | 62kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39656/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
