Specifications
| Measuring range | 50 ~ 1400kpa |
| Clamping Force | 400 ~ 1200KPa |
| Accuracy | ≤±0.5% |
| resolution | 0.01kpa |
| deformation error | ≤1mm |
| Concentricity of Upper/Lower plates | ≤0.25mm |
| Film convex disk pressure | 9mm【（30±5)kPa】 |
| Oil delivery speed | 95±5mL/min |
| Pressure plate diameter | Upper plate diameter: 30.5 ± 0.1mm, lower plate diameter: 33.1 ± 0.1mm |
| Human Machine Interface | 3.4 in 320 * 240 dot matrix liquid crystal display, real-time display of data changes |
| unit conversion | Kg / cm2kpalbf / in2 |
| printout | Modular integrated thermal printer |
| Dimensions | 400*350*500mm |
| Weight | 42Kg |
| Operating Environment | Temperature (20 ± 10) ℃, humidity < 85% |
Packing list
Host X1, sheet X1, power cord X1, correction sheet X5, silicone oil X1 bottle (250ML), trachea X1, filler tube X1, film X2, printing paper X3
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39657/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
