Specifications
| Measuring method | Platinum ring method |
| Measurement range of surface tension | 0~2000mN/m |
| Surface tension Accuracy | 0.1mN/m |
| Liquid density range | 0~3.000g/cm3 |
| Density Accuracy | 0.001g/cm3 |
| Operation mode | Automatic lifting, automatic measurement |
| Lifting speed | 0~300mm/min can be adjusted arbitrarily |
| Temperature Measurement Range | -40 ℃~ 250 ℃ (PT100 Temperature Sensors are required) |
| Display mode | 7-Inch touchscreen, direct data reading |
| data mode | Data storage/view/print support |
| Measurement time | Regular within 60 seconds |
| Interface | RS232 (printer) or USB flash drive |
| Data processing software | Standard ST Flash software |
| Dimension | 47*24.5*47.5cm |
| Horizontal adjustment method | Electronic level adjustment |
| Net Weight | 18kg |
| Power supply Voltage | 110V or 220V, 50W |
| Meet the standard | ASTM D971、ASTM D1331、ASTM D1417、DIN EN 14210、DIN EN 14370、ISO 304、ISO 1409、ISO 6889 |
| Platinum Ring Specifications | The wire radius is 0.185mm, the ring radius is 9.55mm, and the ring circumference is 60mm. |
Packing list
Host * 1, touch screen * 1, test weight * 1, extension hook * 2, tray * 1, platinum ring * 1, Glass ware * 2, forceps * 1, alcoholburner * 1, power cord * 1, display cable * 1, operation manual * 1, U disk * 1, data cable * 1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39698/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
