Specifications
| Power | AC 220V±10% 2A 50Hz |
| Error of indication | ±0.5% |
| Indication of variability | ≤0.5% |
| resolution | 0.1kPa |
| Measuring range | 250 ~ 6000kPa |
| Oil delivery speed | 170±5mL/min |
| Clamping Force | ≤ 1200Kpa |
| Air compressor | Pressure (0.6~ 0.7) MPa; Displacement (0.02~ 0.3) m3/min (non-standard) |
| System tightness | 1Min pressure drop < 10% FS |
| Human Machine Interface | 5-Inch color large touch screen, can switch between Chinese and English |
| printout | Modular integrated thermal printer |
| Communication interface | WAN port (optional)/USB (optional) |
| Operating Environment | Indoor temperature (20 ± 10) ℃; Relative Humidity < 85% |
Packing list
Host X1, sheet X1, power cord X1, correction sheet X5, silicone oil X1 bottle (250ML), trachea X1, filler tube X1, film X2, printing paper X3
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39733/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
