Specifications
| Number of channels | 6 channels |
| Probe Type | K type thermocouple (optional) |
| temperature Measurement Range | -40.0~1370.0 ℃ (optional) |
| temperature measurement Accuracy | ±1 ℃ |
| resolution | 0.1 ℃ |
| Storage Capacity | 2008888 data points |
| Recorder size | 145*60*20 mm |
| Insulation box size | Height 16 cm |
| Power | DC3.7V~DC4.2V |
| Connectivity | wired |
| Sampling frequency | 0.2~ 200.00 seconds |
| data transmission | Wired transmission/wireless transmission (optional) |
| continuous testing | Can be tested multiple times, store up to 16 sets of data |
| Start mode | Button start, delayed start, temperature start |
| Instrument power consumption | 12mAh |
| Instrument temperature resistance | 80.0 ℃ (Maximum Internal Operating Temperature of Recorder) |
| radio frequency | 1.0~100.00 seconds (optional) |
| Stop mode | Press button to stop |
| Battery level | 600mA |
| Calibrated mode | Voltage calibrated, temperature calibrated |
| Measurement time | Heat box temperature 300 degrees measurement time 120min or 400 degrees measurement time 60min |
Packing list
Furnace temperature tester X1, setting software X1, Thermocouple X1, communication data cable X1, heat insulation box X1, instrument box X1, manual X1, warranty card X1, certificate X1, high temperature tape X1, scissor X1, calibrate report X1, high temperature gloves X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39787/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
