Specifications
| Explosion-proof level | EX d e mb IIB T4 Gb |
| Door opening method | Single door |
| Temperature range | RT+10~250°C |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±1℃ |
| Temperature Uniformity | ±2.5% |
| Fan | Explosion-proof fan |
| Enclosure Material | Cold rolled steel plate, surface resistance painting |
| Thermal insulation material | aluminum silicate fiber |
| Heating mode | Explosion-proof stainless steel heating tube (explosion-proof qualification) |
| Rated power | 2.0 kw |
| Exhaust port | Inner diameter 30mm, top mounted |
| Control box | Explosion-proof qualification box centralized explosion-proof design |
| Temperature representation | LCD display (flameproof button) |
| Timer | 0~9999Min (with Timer waiting) |
| Run function | Fixed value operation, Timer operation, automatic stop |
| Program Mode | optional |
| Temperature sensor | 2 pt100 (explosion-proof qualification), 1 control and 1 prevention |
| blower | Explosion-proof special motor (with explosion-proof qualification) |
| switch | Explosion-proof switch (with explosion-proof qualification) |
| External connection | Adopt explosion-proof torsion pipe (explosion-proof qualification) |
| Power cord | Explosion-proof flexible connection, explosion-proof connection plug. |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory |
| Safety Devices | Over-rise protection, leakage current protection, Independent Overtemperature Protection protector (built in the explosion-proof control box, the highest temperature limit). |
| Alarm function | Over-temperature alarm |
| Interior size | 550*450*550mm |
| Volume | 136L |
| Load per shelf | 15kg |
| Shelf (std.) | 2pcs |
| Power | AC220/50-60Hz,9.1A |
| Optional accessories | Shelf, RS485 interface, printer, recorder, external communication, remote control, programmed temperature Controller, unlimited SMS alarm, U disk data storage. |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39790/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
