Specifications
| Volume | 50L |
| Temperature and humidity control instrument | Programmable TEMP8226S imported from Korea, touch screen input, different temperature points can be arbitrarily set according to customer requirements |
| Temperature shock range | -60 ℃~ + 150 ℃ (programmable to set arbitrarily) |
| Regenerator temperature range | 0 ℃~ + 180 ℃ (programmable to set arbitrarily) |
| Cold storage box temperature range | 0 ℃~ -70 ℃ (programmable to set arbitrarily) |
| Controller control Accuracy | ±0.2℃ |
| temperature shock rate | Complete in 30 seconds |
| Enclosure Material | Premium stainless steel plate |
| Liner material | SUS #304 Heat-resistant and cold-resistant stainless steel plate, first-class light panel |
| Thermal insulation material | High Density Glass Cotton and High Strength PU Foam Insulation Material |
| Box uniformity | ±2℃ |
| Air supply circulation system | Daily multi-wing centrifugal Circulating Fan, daily motor whole group |
| Heating system | U-shaped fin type 304 #seamless steel high-speed heating electric heater |
| Refrigeration system | Using French Taikang compressor |
| Refrigeration accessories | Table bend center force evaporator, Marr fan, etc |
| Refrigeration system | air cooled |
| Test box load | 10KG |
| Protection device | Compressor overheating, overtemperature, overload, high pressure, low pressure, oil pressure, overcurrent, under-phase, power failure standby and other alarm warnings |
| Power | AC380V 50~60Hz 18KW |
| Standards | GB2423 [1] .02 High temperature test method, GB2423 [1] .01 Low temperature test method |
| Controller display | 5.7-Inch color touch screen |
| Control method | program |
| Sensors Type | PT100 Sensors Input |
| Output method | PID control output; (4-20mA) analog circuit output; 8-channel switching signal auxiliary input; (basic configuration of 10 relays, optional 20 relays) |
| Temperature Measurement range | -200.00 ℃ --300.00 ℃, error ± 0.2 ℃ |
| Program editing | There are three types of programs, namely 2ZONE, 3ZONE, STEP |
| language | Chinese and English can be switched |
| Controller Power | Rated Voltage: 85-265V AC, 50/60Hz, lithium battery for at least 10 years, withstand Voltage 2000V AC/1 minute |
| Controller Dimensions | 184 × 144 × 94 (mm) (L × W × D) |
| Controller mounting opening size | 173 × 133 (mm) (L × W) |
| TFT resolution | 640 × 480 64k color |
| Basket size | W40cm*D20cm*H30cm |
| Lead test hole | without |
| Display resolution | Temperature: 0.01 ℃; Time: 0.01 min |
| input | thermocouple |
Packing list
Complete-built unit x1, manual x1, certificate of conformity
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39832/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
