Specifications
| Liner size | 600*600*600mm |
| Liner material | High grade stainless steel plate SUS304 |
| Standards | GB4208-93 |
| Outer box size | 1750*1250*1450mm |
| Enclosure Material | High grade stainless steel plate SUS304 |
| Box door | Large Tempered Glass Observation Window |
| Air duct system | Unique air duct design ensures that the box generates non-layered vertical circulating airflow |
| Box temperature | RT+10~60°C |
| The Relative Humidity in the box | 45%~75%RH |
| Nominal net diameter | 50um |
| Nominal spacing between lines | Not more than 70um |
| Amount of dust in the box | 2Kg/m |
| Airflow velocity | ≤2m/s |
| Talc powder dosage | 2kg~4kg/ m3 |
| Dust blowing time | 0~9999.9h can be set |
| Control system | Imported high-precision PID digital display instrument |
| Safety protection device | Instrument over-temperature protection function, Power phase loss protection, leakage circuit breaker protector |
| Power | AC220V 50Hz |
| air temperature | 0～35℃ |
| Relative Humidity | 25%～75%RH |
| Input power | About 2KW |
Packing list
complete-built unit X1, plate X2, damp cloth X3, silicone plug X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39834/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
