Specifications
| Clamping Force | > 690Kpa |
| induction method | pressure converter |
| Savings Results | With printing function, 10 sets of data can be printed to automatically calculate the average value |
| Display | High definition LCD display, digital A/D value advance rate 100 times/S, high test Accuracy |
| unit conversion | Kgf/cm2, Lb/in2, Kpa (with unit switching function) |
| Measuring range | 250 ~ 6000kPa |
| resolution | 1kPa |
| Error of indication | ≤±1%FS |
| Indication of variability | Better than ± 1% |
| Oil delivery speed | 170±10mL/min |
| Film resistance | Raise 10mm, 170kPa~ 220kPa; Raise 18mm, 250kPa~ 350kPa |
| Clamp ring material | stainless steel |
| Upper clamp ring aperture | F (31.5 ± 0.05) mm |
| Lower clamp ring aperture | F (31.5 ± 0.05) mm |
| Upper chuck diameter | 95mm |
| Lower chuck diameter | 135mm |
| hydraulic oil | silicone oil |
| Volume | 430*530*520mm |
| Weight | About 70Kg |
| Power | 1∮,AC220V |
| Standard configuration | 5 pieces of rubber film, 1 wrench, 10 correction pieces, and 1 bottle of silicone oil. |
Packing list
complete-built unit X1, plate X2, damp cloth X3, silicone plug X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39836/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
