Specifications
| material | The fuselage is made of stainless steel as a whole, which is resistant to acid and alkali and corrosion |
| structure | Drawer type sample table, simple and convenient to take and put the substrate |
| gas path | Reserve the air inlet interface to enrich the cleaning types of equipment |
| protect | Drawer opening and closing work interlock with UV lamp to avoid UV damage |
| Timer | Button timer, digital countdown, intuitive |
| operation | The cleaning process can be terminated manually at any time |
| Accessories | Optional ozone neutralizer to avoid ozone damage |
| Cleaning band | 185Nm and 254nm |
| Average light intensity of 3-5mm from UV lamp | 28~32mW/cm² |
| lamp | Double wave low pressure mercury lamp |
| Lamp power | 150W |
| Irradiated area | 150mm×200mm |
| Adjustable irradiation distance | 5~40mm |
| Timer working interval | 0~99min99s with automatic countdown function |
| Inlet and outlet | Air inlet: φ8mm, air outlet: φ25mm |
| Equipment appearance size | 250mm（W）×300mm（D）×260mm（H） |
| Pallet size | 160mm（W）×200mm（D）×5~30mm（H） |
| Product Weight | 8 KG |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39846/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
