Specifications
| Coating method | Bar + adjustable drawdown blade |
| Drawdown blade type | Split drawdown blade |
| Drawdown blade thickness range | 0~5000μm |
| Drawdown blade Accuracy | ±10μm |
| Drawdown blade material | aluminum alloy |
| Drawdown blade size | 214*76*100mm |
| Net Weight of drawdown blade | 500g |
| Coating speed | 5-200Mm/s (< 5mm/s can be customized) |
| Coating size | 300 * 400Mm (Miscellaneous size can be customized) |
| Spreader distance control | The number can be set arbitrarily within the range of 1-400mm |
| Drawdown blade application width | 200mm |
| Mayer Rod Thickness Range | 1-571.5 μm (Spreader thickness according to bar model) |
| Mayer Rod Accuracy | ±0.001mm |
| Host Power Supply | 220V 50HZ 1700W |
| Dimension | 626*410*520mm |
| Net Weight | 55KG |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Substrate clamping method | Mechanical fixture |
| Control mode | Touch screen control |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Automatic lame plating device, UV curing device, automatic inking system, air knife drying, remote control, upper infrared heating, double extrusion Spreader |
Packing list
Film Applicator X1, China bar X1, Drawdown blade X1, Product manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39857/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
