Specifications
| Power supply Voltage | AC100～240V，50Hz/60Hz 100W |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity ≤ 85% |
| show | 7-Inch color touch screen |
| Error of indication | +/- 0.5% (range 5%~ 100%) |
| Indication resolution | 0.1N |
| Indication variability | ≤0.5％ |
| Test speed | (12.5 +/- 1) mm/min, (1~ 500) mm/min adjustable |
| Parallelism of Upper/Lower platens | ＜0.02mm |
| Maximum distance between Upper/Lower platens | 80mm |
| Thermal printer | |
| Communication interface | RS232 (default) (USB, WIFI optional) |
| Dimensions | 415×370×505mm |
| Net Weight of instrument | About 58kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/39985/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
