YIHENG DHG-9145A Electric Forced Air Drying Oven 2050W Input Power

DHG-9145A

Drying Oven

With reliable temperature control (RT + 10~300 ℃， +/- 1.0 ℃ Temperature Fluctuation, 0.1 ℃ Temperature resolution) and Temperature uniformity （ +/- 3%), large volume (136L) and spacious Interior size (550 * 450 * 550mm), high input Power (2050W) and flexible Timer Range (1~ 5999 minutes), Net weight 68kg, gross weight 105Kg, and equipped with 2 shelves. Suitable for working Environmental temperature from 5~ 40 ℃, Dimension is 840 * 670 * 730mm, packing size is 940 * 780 * 950mm.

Introduction of DHG-9145A electric Forced Air Drying Oven

Yiheng DHG-9145A electric Forced Air Drying Oven is an intelligent electric Forced Air Drying Oven, which is used for drying, sterilizing and baking in the laboratory. The input power of DHG-9145A electric Forced Air Drying Oven is 2050W, and the volume is 136L. It can be equipped with multi-segment programmable liquid crystal temperature controller to realize independent control and operation.

Features

1. Adopt a microcomputer PID temperature controller with over-temperature deviation protection and digital display, with timing function, and the temperature control is accurate and reliable. ,

2. The inside of the box is made of mirror stainless steel argon arc welding, and the outside of the box is made of high-quality steel plate, which is beautiful and novel in shape.

3. The air intake and exhaust volume in the box can be adjusted from the temperature control panel.

4. The hot air circulation system is composed of a fan that can operate continuously at high temperature and a suitable air duct to improve the temperature uniformity in the working room.

5.DHG-9145A Electric Forced Air Drying OvenIt adopts a new type of synthetic silicon sealing strip, which can run at high temperature for a long time, has a long service life and is easy to replace.

6. Independent temperature limit alarm system, which will be automatically interrupted when the temperature exceeds the limit, so as to ensure the safe operation of the experiment without accidents. (optional)

7. It can be equipped with a printer or RS485 interface, used to connect a printer or computer, and can record the change of temperature parameters. (optional)

Optional

1. Multi-segment programmable temperature controller

2. Independent temperature limit controller

3. RS485 interface and communication software

4. Embedded printer

5. Diameter Ф25mm test hole

6. U disk data storage

7. Wireless alarm system (SMS alarm system)

Pictures

Packing list： host x1, instruction manual x1, packing list x1, warranty x1, warranty card x1, fuse x2, shelf x2, communication data cable x1, software CD x1, printing paper x1, U disk x1, UV lamp x1

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
