Specifications
| Ozone concentration range | 50~500pphm |
| Temperature range | 0℃~70℃ |
| Humidity range | ≥65%R.H |
| Interior size | 700*800*900mm |
| Dimension | 1450*1400*2250mm |
| Power | 7.0kw |
| Temperature Fluctuation | ±0.5℃ |
| test device | Dynamic, static (optional) |
| Rotation speed | 360 degree swirl/spin sample holder (Rotation speed 1 rpm) |
| Flow velocity | 12~16mm/s |
| temperature Controller | Imported LED digital display P.I.D + S.S.R. microcomputer integrated Controller |
| time Controller | High-precision hour, minute, second time Controller |
| Ozone concentration analysis | Imported concentration analysis regulator 4~ 20mA output, RS232 communication port |
| Ozone generator | Silent discharge tube |
| Safety protection | Leakage, short circuit, overtemperature, motor overheating, overcurrent protection |
| meet the standard | GB/T7762-2003、GB/T2951.21-2008 |
| Volume | 500L |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/40027/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
