Specifications
| Measurement range | 0~10mm |
| Measurement Accuracy | +/- 0.003mm or +/- 0.5% |
| Power Supply | AC(100~240)V，(50/60)Hz 50W |
| Operating Environment | Temperature (10~35) ℃, Relative Humidity ≤ 85% |
| show | 5-Inch color touch screen |
| Graduation | 0.001mm |
| Error of indication error of indication | ≤ 0.003Mm or ≤ 0.5% |
| Measurement of parallelism between planes | ≤0.0004mm |
| Contact area | (1000±5) mm² |
| Contact Pressure | (2±0.1)kPa |
| Probe descent speed | (0.5~ 10) mm/s adjustable |
| Thermal printer | |
| Communication interface | RS232 (default) (USB, WIFI optional) |
| Dimensions | 325×310×485 mm |
| Net Weight of instrument | About 24kg |
| standard basis | GB/T 451.3，QB/T 1055，GB/T 24328.2，ISO 534 |
