Specifications
| Stirring blade | 2 layers of 4 pieces × 45 ° |
| Stirring blade running diameter | Φ230mm |
| Rotation speed of stirring blade | (Clockwise) 80 +/- 4r/min |
| Rotation speed of stirring drum | (Counterclockwise) 60 +/- 2r/min |
| Mixing drum Capacity | 28L |
| Mixing drum rated Capacity | (Discharge) 15L |
| Mixing cylinder inner diameter | Φ380mm |
| Mixing barrel depth | 290mm |
| The gap between the fixing blade and the wall of the stirring cylinder | 2±0.5mm |
| The distance between the stirring blade and the bottom of the stirring cylinder | 2±0.5mm |
| Power supply Voltage | 380V |
| Power | 1500W |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/40047/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
