Specifications
| Speed range | 0/30-2000rpm |
| Rotation speed display | LED seven zones |
| Processing Capacity | 25L |
| maximum viscosity | 30000mPas |
| Input Power | 150W |
| output power | 105W |
| Speed regulation mode | stepless |
| Max Torque | 40Ncm |
| drive type | Brushless DC motor |
| Maximum output power of mixing shaft | 105 W |
| Permissible continuous running time | long continuous |
| Rotation speed control Accuracy | 1±rpm |
| Speed measurement deviation at n > 300rpm | 1±% |
| Speed measurement deviation at n < 300rpm | 3±rpm |
| Impeller fixing method | Collet |
| Rotary collet clamping range | 0.5~10mm |
| Hollow shaft, inner diameter | 11mm |
| Hollow shaft (stop state, can be inserted) | Yes |
| bracket fixing | Extension arm chuck fixed |
| Extension arm diameter | 16mm |
| Extend arm length | 230mm |
| Speed control | electronic |
| Rated torque | 0.4Nm |
| Shell material | Cast aluminum coating/thermal plasticity polymer |
| Weight | 3kg |
| Ambient Temperature | 5-40 ℃ |
| Allowable Relative Humidity | 80% |
| DIN EN 60529 Protection method | IP42 |
| Power | 230/115/100V |
| Rated Frequency | 50/60Hz |
| Input Power | 150W |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
