Specifications
| Drawdown blade Accuracy | ±5μm |
| Drawdown blade thickness range | 0~10mm |
| Coating speed | 2~50mm/s |
| Coating size | 300*400mm |
| Vacuum Area | 300 * 400Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Drawdown blade application width | 300mm |
| Coating rod application width | 300Mm (Spreader thickness determined according to the rod model) |
| Host Power | 220V 50Hz |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Coating rod specification | Standard 1 China wire rod |
| Spreader Accuracy | ±5μm |
Packing list
Film Applicator X1, External vacuum pump X1, doctor blade X1, China wire rod X1, product manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/40058/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
