Specifications
| Combustion size | Inner Diameter Should be 9.5mm +/- 0.3mm, Length 100 +/- 10mm |
| flame height | 20Mm +/- 2mm to 175mm +/- 1mm adjustable |
| Flame time | 0~999.9S +/- 0.1s adjustable |
| afterflame time | 0-999.9S +/- 0.1s, automatic recording, manual pause |
| Combustion gas | 98% methane gas or 98% propane gas (in general, liquefied petroleum gas can be used instead) |
| Flow rate pressure | Dual flow gauges and dual pressure gauges (gas and air) |
| Glowing wire temperature | 0~1000℃ |
| Thermocouple | φ 0.5mm imported armoured (K type) Thermocouple |
| experimental background | Black Background |
| Test process | Test procedure Manual control, independent ventilation |
| Studio Volume | 0.5m3 |
| Equipment external Dimensions | 1000Mm wide × 650mm deep × 1300mm high |
| material | Inner and outer 304 stainless steel |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/40147/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
