RONGHUA RHDCY-36 Dry Nitrogen Evaporator 36-hole nitrogen purge instrument

SE
Simultaneous processing of 36 samples, standard with a heating block, digital temperature control, temperature control up to 150 ℃, using aluminum bathroom block.
$997.00/set
PromotionLoading...
Coupon
Model：
Certificate
Contact
Details SPEC Con

RONGHUA RHDCY-36 Nitrogen EvaporatorSPEC

RONGHUA RHDCY-36 Nitrogen EvaporatorDetails

RONGHUA RHDCY-36 Nitrogen EvaporatorPacking list

SKU
NB040248
Number of processed samples
12
Module aperture
Φ16mm * Hole depth 50mm
Heating power
200W
Gas flow meter
0~15L/min
Standard number of heating blocks
one
temperature control Accuracy
±0.5℃
display Accuracy
±0.1℃
Timer
99 hours 59 minutes
Temperature range
RT+5~150°C
Temperature control method
Digital temperature control
Maximum lifting stroke
200mm
Dimensions
280*240*500mm
Weight
7KG
RHDCY-36
Nitrogen Evaporator
Simultaneous processing of 36 samples, standard with a heating block, digital temperature control, temperature control up to 150 ℃, using aluminum bathroom block.
RONGHUA RHDCY-36 Dry Nitrogen Evaporator 36-hole nitrogen purge instrument Picture

Introduction

The Principle of the nitrogen purging instrument is to quickly, continuously and controllably blow nitrogen to the surface of the heated sample, set the heating temperature according to the evaporation rate and boiling point of the concentrated solvent, and realize the rapid concentration of a large number of samples. The instrument adopts an aluminum block bathroom, which has good heat transfer and uniform heat transfer, which is conducive to rapid heating and rapid temperature control. Nitrogen gas is blown onto the sample surface to achieve oxygen-free concentration of liquid samples. The blowpipes are independent of each other and will not cause cross-contamination. Each air needle channel on the air distribution assembly can be used in combination or alone. The system has high temperature control accuracy, wide temperature control range, digital temperature display, and convenient temperature calibration. The appearance of the product is elegant, easy to use, safe and reliable to use.

Comparison of parameters of dry Nitrogen Evaporator series

Product numberZGDCY-12 (12 holes)ZGDCY-24 (24 holes)ZGDCY-36 (36 holes)
Number of samples processed122436
Module ApertureФ16mm*hole depth 50mm
heating power200W
Barometer0－15L/min
Standard number of heating blocksone
Temperature control accuracy±0.5℃
display accuracy±0.1℃
Timer Range99 hours 59 minutes
Temperature control rangeRoom temperature +5°C~150°C
Temperature control methodDigital temperature control
Maximum lifting stroke200mm
Dimensions280mm*240mm*500mm
weight7KG7.5KG8KG


FAQ
QIs the price listed on the website the final cost for overseas purchases?
ANo, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.
QWhat is the specific process for purchasing the product?
AFirst, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.
QWhat should I do if the instrument I purchase needs repair?
AAfter-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
