Specifications
| Force range | 1~5000N |
| Plate size | 300*200*300mm |
| Force Accuracy | +/- 1% or less |
| test function | Measurement of compressire strength, determination of compression strength, determination of constant strength, determination of resilience after compression |
| Sensing deformation error | ≤±1mm |
| Sensors Analytical Accuracy | 0.3% |
| Plate parallelism | ≤±0.5mm |
| Deformation Accuracy | ≤0.05mm |
| Pressurization speed | 5~ 300mm/min stepless adjustable |
| Unit switch | Force value unit: N/Lbf /kgf/gf/KN, strength unit: kPa, MPa |
| Data analysis | 7In touch screen, with Linear dispersion analysis, thermal printing integrated, with Linear dispersion analysis chart |
| Computer control | Computer-specific analysis software, Linear dispersion detail analysis, with dedicated programmable file management analysis report, A4 printing (optional) |
| Safety Devices | 1. Stroke protection: high is the Upper/Lower limit protection switch to prevent exceeding the preset stroke; 2. Force protection: the system can set the force value to prevent exceeding the sensor calibration value; 3. Emergency stop device: This high is equipped with an emergency stop switch, which can handle emergencies; |
| Operating Environment | Temperature (20 +/- 10 ℃), Humidity < 85% |
| Power Supply | 220V/50Hz |
| power | 400W |
| Dimensions | 550*400*850mm |
| Weight | 135kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/40601/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
