Specifications
| Power supply Voltage | AC220V 50Hz |
| Rated Power | 1500W |
| Display mode | LCD touch screen |
| Temperature range (no load, Environmental temperature < 28 ℃) | ＜-80℃ |
| lyophilized area | 0.094㎡ |
| Cold trap size | Φ240mm×260mm |
| Maximum vacuum | ＜ 10pa |
| water capture Capacity | 4Kg/24h |
| Shelf layer | / |
| Material tray specifications | Φ200mm |
| Material tray spacing | / |
| Disk material Volume | 1L |
| Standard number of trays | 3 |
| Number of manifolds | 8 |
| Transparent cover specification | Φ260×400mm |
| Net Weight | 140kg |
| Dimensions | 860×520×710+400mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/40618/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
