Specifications
| Volume | 250L |
| Lighting method | Three-sided lighting |
| light intensity | 0~15000Lx |
| Light level | Level 6 |
| Liner size | 500*530*950mm |
| Liner material | stainless steel plate |
| Dimensions | 690*705*1674mm |
| Temperature range | No humidification: 0~65 ℃; Humidification: 10~65 ℃ |
| Temperature Resolution | 0.1℃ |
| Temperature Fluctuation | ±1℃ |
| temperature distribution | ±1.5℃ |
| Humidity control range | 40%~90%RH |
| Humidity stability | ±7%RH |
| Exterior | Cold rolled steel plate, surface resistance painting |
| Thermal insulation material | Polyurethane |
| heater | Stainless steel heating tube |
| Rated power | 1.0KW |
| compressor | Air-cooled closed compressor |
| refrigerant | R134A |
| Defrost structure | automatic |
| Humidity control mode | automatic |
| Lead Hole | without |
| Temperature Control mode | 30-Segment liquid crystal program |
| Temperature setting | Touch key settings |
| Temperature representation | Measuring temperature display: liquid crystal upper display; setting temperature display: liquid crystal lower display |
| Timer | 0~99.9h * 30 (with Timer and waiting function) |
| Run function | Fixed-value operation, scheduled operation, automatic stop/reservation start, program operation |
| Program Mode | Standard |
| Additional features | Deviation correction, menu button lock, power outage compensation, power outage memory, loop self-diagnosis, intelligent defrosting |
| Sensors | PT100 |
| Safety Devices | Overrise alarm, overload protection, circuit self-diagnosis |
| Packing size | 850*880*1790mm |
| Shelf load bearing | 15kg |
| Shelf (max.) | 6pcs |
| Shelf spacing | 120mm |
| Power supply (50/60Hz) rated current | AC220V/4.5A |
| Net Weight | 76kg |
| Gross Weight | 117kg |
| Shelf (std.) | 2pcs |
| Shelf | 4 pieces |
| Optional Accessories | Shelf, RS485 interface, printer, recorder, external communication, remote control, wireless SMS alarm, U disk Data storage, inflatable port |
| Light level | Six-level adjustable |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
