Temperature test paper, Yadongxing BC60 60 ℃ one temperature point (72 pieces)

BC60

Thermometric Paper

product description

Yadongxing BC type temperature measuring paper is a temperature measuring paper with pressure sensitive adhesive, there are nine types of temperature 50/55/ 60/65/70/75/80/85/120 ℃ to choose from, but the temperature often changes color series. BC 50/55/ 60 /65/70/75/80/85/120 temperature measuring papers are all irreversible temperature measuring papers with only one temperature point and the specification is 2x2cm/sheet. After each temperature is overheated, it will turn into red, black, green, yellow and other colors, and there is a protective film on the surface. Yadongxing BC type temperature measuring paper is often used for temperature tracking of equipment in the railway industry.

Product parameters

How to paste the temperature measuring paper

1. The temperature measuring part where the temperature measuring paper is to be pasted should be kept flat, clean and dry. It is better to use sandpaper to remove the oxide layer or uneven surface, or use gasoline and other suitable solvents to clean and wipe it again.

2. First bend the BC 50/55/60/65/70/75/80/85/120 temperature measuring paper and then uncover it ( if you are not very skilled in removing it, you can use a knife to shovel it from the side along the bottom paper )

3. There is a pressure-sensitive adhesive on the surface of the temperature measuring paper. When pasting it, press it firmly to eliminate the tiny air gap between the glued surfaces, so that the glue surface is under pressure to play an adhesive role, and ensure that the temperature measuring paper can be firmly adhered to the measuring surface. Warm parts, not easy to drop.

4. If it is to be pasted on a part that may be stained with oil or water, another series of temperature measuring patches with a protective film should be selected.

Note: If it is in a particularly harsh place, it is recommended to wrap a larger transparent tape, which can play a better role in protection and fixing.

Pictures

Packing list：Thermometric Paper x1 (72 pieces/sheet)

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
