Temperature indicator card, there is a protective film on the surface of Yadongxing BC85 85 ℃ (72 pieces)

BC85

Thermometric Paper

product description

Yadongxing BC temperature indicator card is a temperature indicator card with pressure sensitive adhesive, there are nine types of temperature 50/55/60/65/70/75/80/85/120℃ to choose from , but the temperature changes color series. BC 50/55/60/65/70/75/80/85/120 temperature indicator cards are irreversible temperature measuring paper with only one temperature point, and the specification is 2x2cm/piece. After each temperature is overheated, it will turn into red, black, green, yellow and other colors, and there is a protective film on the surface. Yadongxing BC temperature indicator card is often used for temperature tracking of equipment in the railway industry.

Product parameters

How to Paste and Use the Temperature Indicator Card

1. The temperature measuring part to be pasted on the temperature indicator card should be kept flat, clean and dry. It is better to use sandpaper to remove the oxide layer or uneven surface, or use gasoline and other suitable solvents to clean and wipe it again.

2. First bend the BC 50/55/60/65/70/75/80/85/120 temperature measuring paper and then uncover it ( if you are not very skilled in removing it, you can use a knife to shovel it from the side along the bottom paper )

3. There is a pressure-sensitive adhesive attached to the surface of the temperature indicator card. When pasting it, press it firmly to eliminate the tiny air gap between the glued surfaces, so that the glued surface can be bonded under pressure to ensure that the temperature measuring paper can be firmly adhered to the measuring surface. Warm parts, not easy to drop.

4. If it is to be pasted on a part that may be stained with oil or water, another series of temperature measuring patches with a protective film should be selected.

Note: If it is in a particularly harsh place, it is recommended to wrap a larger transparent tape, which can play a better role in protection and fixing.

Pictures

Packing list：Thermometric Paper x1 (72 pieces/sheet)

[Note]Because the manufacturer's packaging may be updated or upgraded, the detailed packaging list shall be subject to the latest standard configuration of the manufacturer.
