Specifications
| Application mode | Adjustable roller application |
| Effective Application Width | 0-400mm |
| Application rate | 0-5m/min |
| Heating method | Stainless steel electric heating tube heating, centrifugal fan hot air circulation |
| Heating temperature range | RT+~200°C |
| Host Power | 220V 50Hz |
| Dimensions | ≈1500mmX600mmX750mm |
| Roll surface width | 400mm |
| Unwinding diameter | ≤ 400mm |
| winding diameter | ≤ 400mm |
| Unwinding Unit - Type | Single station |
| Unwinding Unit - Effective Unwinding Width | 400mm |
| Unwinding Unit - Effective Unwinding Diameter | ≤ 400mm |
| Unwinding Unit - Unwinding Reel | Inflatable shaft |
| Unwinding Unit - Unwinding Tension Control | Tension Controller automatic control |
| Extrusion Unit - Extrusion Method | Double roll extrusion |
| Extrusion Unit - Double Roll Material | Plating roller |
| Extrusion Unit - Adjustable Range | 0.3-10mm |
| Extrusion Unit - Application Film thickness | 0.3-10mm |
| Extrusion Unit - Application Adjustment | Handwheel adjustment, dial meter display |
| Extrusion Unit - Application Accuracy | ±0.05mm |
| Extrusion Unit - Dip Tray Material | 304 stainless steel |
| Oven Unit - Type | Column arch bridge type; unilateral pneumatic jacking type |
| Oven Unit - Length | Oven: 1000mm |
| Oven Units - Materials | stainless steel |
| Oven unit - temperature | Room temperature~ 200 ℃ ± 3 ℃ |
| Oven unit - temperature control | Digital temperature control meter automatic proportional temperature control |
| Oven Unit - Insulation | Glass fiber filled with insulation layer |
| Winding Unit - Type | Single station |
| Winding Unit - Effective Winding Width | 400mm |
| Winding Unit - Effective Winding Diameter | ≤ 400mm |
| Winding Unit - Winding Reel | Inflatable shaft |
| Winding Unit - Winding Tension Control | Tension Controller automatic control |
Packing list
Complete-built unit x1, manual x1, certificate of conformity
After-sales instructions
Warranty days: 365 days
The product is a non-standard product, non-artificially caused by product quality problems, does not support return and exchange service, and provides 1-year free warranty service.
