Specifications
| Dimensions | 1845*1480*2100mm |
| Liner size | 510*520*400mm |
| Temperature range | -70℃~150℃ |
| Temperature Uniformity | ±2℃ |
| Heating rate | -40 ℃~ 100 ℃ About 55min |
| Cooling rate | 25℃→-70℃≈60min |
| Control mode | P, I, D + S, S, R. Microcomputer integrated Controller |
| Accuracy range | Setting Accuracy: temperature +/- 0.1 ℃, indicating Accuracy: temperature +/- 0.1 ℃, resolution: +/- 0.1 ℃ |
| Temperature and Humidity Sensors | Industrial Platinum Resistor PT100Ω/MV A |
| Heating system | Full vertical system, low thermal resistance nickel-chromium alloy wire electric heating device |
| Refrigeration system | Fully enclosed air-cooled cascade compression refrigeration method |
| Circulatory system | Temperature-resistant and low-noise air-conditioned motor. Multi-wing stainless steel centrifugal wind turbine |
| Enclosure Material | Carbon steel plate. Electrostatic phosphating spray treatment/SUS304 stainless steel matte line hair pattern treatment |
| Liner material | SUS304 stainless steel plate |
| Insulation material | High density polyurethane rigid foam, ultra-fine fiberglass cotton |
| Door frame insulation | Double-decked high and low temperature aging resistant silicone rubber door sealing strip |
| Standard configuration | Glass window 1 set, test rack 2, test lead hole (50mm) 1 |
| Protection device | Leakage, short circuit, overheating, motor overheating, compressor overVoltage, overload, overcurrent protection |
| Timer | 0.1~ 999.9 (S, M, H) adjustable |
| Power | AC380V +/- 10% 50 +/- 0.5Hz three-phase five-wire system |
| Ambient Temperature | 5℃~＋30℃ ≤85％R.H |
| Temperature Fluctuation | ≤±0.5℃ |
