Specifications
| Inner box size | H1000*D1000*W1000(mm) |
| Outer box size approx | H2000*D1450*W1740(mm) |
| Internal and external materials | High grade stainless steel plate SUS304 |
| Box temperature | 15~35°C |
| The Relative Humidity in the box | 45%~75%RH |
| Nominal net diameter | 50um |
| Nominal spacing between lines | Not more than 70um |
| The amount of dust in the box is | 2Kg/m |
| Airflow velocity | ≤2m/s |
| Talc powder dosage | 2kg~4kg/ m3 |
| Dust blowing time | 0~9999.9h can be set |
| Power | AC380 V 50Hz |
| air temperature | 0～35℃ |
| Relative Humidity | 25%～75%RH |
| Atmospheric pressure | 86 ping 106kpa |
| Rated Voltage | AC220V |
| Rated Frequency | 50HZ |
| Input Power | About 2KW |
| Talc powder dosage | 2kg/m3 |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41409/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
