Specifications
| Inner box size | 800*800*800mm |
| Internal and external material | Liner is stainless 304 steel; outer box stainless steel 304 |
| Rotation speed of test bench | Adjustable from 1 to 5rpm |
| Water spray ring radius | 300mm |
| Spray pipe swing angle range | 45 °, 90 ° 340 ° (can be set) |
| Spray hole diameter | f0.4mm |
| Spray aperture spacing | 50mm |
| Flow rate of each spray hole | 0.07 L/min +5% |
| Water spray pressure | 80-150Kpa |
| Swing tube swing | Maximum +/- 170 ° |
| Spray pipe swing speed | IP3 15次/min; IP4 5次/min |
| test time | 1-999,999min (can be set) |
| Control system | Self-developed Touch Screen Control system. |
| Power | 220V 50Hz |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41439/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
