Specifications
| Test chamber size | 800*800*850mm |
| Test chamber outer box size | 1180*1040*1650mm |
| High Voltage sprinkler | It is installed on the left side, welded with stainless steel, and connected to the box. A bracket is installed before and after the water spray pipe, and the height of the bracket can be adjusted. |
| Spray system | It consists of a water pump, a water pressure gauge, and a fixed nozzle bracket. |
| Sprinkler | 2, including 1 IP6 nozzle and 1 IP5 nozzle. |
| pipe diameter | Six points, Liansu PVC pipe |
| Nozzle inner diameter | Φ6.3mm, IP5 (grade), φ12.5mm, IP6 (grade) |
| Water spray pressure | 80-150kpa |
| Flow rate | IP5 (grade) 12.5 +/- 0.625 (L/min), IP6 (grade) 100 +/- 5 (L/min) |
| turntable | 500mm Touch Screen Display Rotation speed |
| Spray duration | 3, 10, 30, 9999min (adjustable) |
| runtime control | 1~ 9999Min (adjustable) |
| water circulation system | Ensure water recycling |
| Water spray pressure gauge | Display water spray pressure |
| Control system | "HUD" Touch screen Control system Control system |
| Laboratory material | The inner stainless steel plate is used as the waterproof wall, and the outer box and square pass bracket are all painted. |
| Nozzle material | 304 stainless steel pipe |
| Water tank material | 304 stainless steel |
| Frame material | Stainless steel square pass, paint |
| Electrical control accessories | Select Chint, Schneider, Taiwan, China Shiyan, Japan Fuji and other well-known brands |
| Nozzle material | 304 stainless steel pipe |
| Nozzle material | SUS304 stainless steel plate |
| Countertop material | SUS304 stainless steel |
| IP56 internal stent | Stainless steel square pass, PVC pipe |
| High power water pump | 2.2KW, multiple solenoid valves control the waterway |
| IP56 Control system | Operate together, IP level optional test |
| Total Equipment Power | 3.8KW |
| Equipment Voltage | 380V |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41442/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
