Specifications
| Inner box size | 500*600*750mm |
| Sample size | 350X350mm |
| Turntable diameter | 600mm |
| Power | 380V / 12KW |
| IPX34-pendulum tube | Radius 400mm, (standard) Miscellaneous size can also be customized |
| IPX34-Inner diameter of pendulum tube | ¢16mm |
| IPX34-Nozzle inner hole | 0.4mm |
| IPX34-Spray hole distance | 50mm |
| IPX34-pendulum tube material | 304 stainless steel industrial pipe |
| IPX34-Nozzle Angle | IPX3: 120 °, IPX4: 180 ° |
| IPX34-pendulum tube angle | IPX3:120 °, IPX4:320 ° (approximate) |
| IPX34-Spray Pipe Swing Speed | IPX3 15 times/min; IPX4 5 times/min about 2X360 degrees/12 S |
| IPX34 - rain water pressure | 80 ping 150Kpa |
| IPX34 - Flow rate | R400 pendulum tube: 1.75L/M |
| IPX34 - Flow rate calculation | Number of nozzle holes X0.07L/M = Flow rate of the water outlet of the pendulum pipe, the flow rate of the water spray can be set |
| IPX56-Spray System | 1 IPX5 nozzle, 1 IP6 nozzle |
| IPX56-Nozzle Aperture | IPx5: ¢6.3mm, IPx6: ¢12.5mm |
| IPX56-Nozzle Connectivity | Threaded connection, looper connection with water pipe, simple and convenient operation |
| IPX56 - Flow rate | IPX5: 12.5L / M ± 0.625L, IPX6: 100L / M ± 5L |
| IPX56 - Injection time | Universal standard 3 minutes, or more time can be set |
| IPX56-Injection distance | The sample is 2.5-3 meters away from the nozzle, and the distance is controlled by the Tester |
| IPX56-Nozzle Connection Hose | Inlet transparent hose with stainless steel wire |
| IPX56-Nozzle Material | 304 stainless steel |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
