Specifications
| temperature Measurement Range | -200～1300℃（-328℉～2372℉） |
| Number of channels | 8 channels |
| Standards | GB/T30429-2013 |
| thermocouple | K type |
| precision | 0.2%+1℃ |
| resolution | 0.1℃（0.1℉） |
| Accuracy | -200 degrees to 0 degrees (read value x0.5% + 2) ℃; 0 degrees to 200 degrees (read value x0.5% + 1.5) ℃; 201 degrees to 1300 degrees (read value x0.5% + 2) ℃ |
| acquisition rate | 1.5 seconds |
| J-type thermocouple (optional) | -200~1200℃（-328℉～2192℉） |
| T-type thermocouple (optional) | -200~400℃（-328℉～752℉） |
| Type E thermocouple (optional) | -200~1000℃（-328℉～1832℉） |
| N-type thermocouple (optional) | -200~1300℃（-328℉～2372℉） |
| Computer analysis software | optional |
| Data record storage | Local storage, U disk storage |
| Data record export | U disk and local connection export/computer and local online view Txt document |
| Time record storage | Yes. |
| Storage Capacity | The local storage without an external U disk can be stored for 3.5 days (5-second recording interval), and the external U disk supports a maximum Capacity of 32G |
| Temperature record storage | Yes. |
| Time display | Yes (year~ month~ day hour: minute) |
| Time setting | Yes. |
| Linear dispersion chart | The menu interface of the machine can be used for temperature recording and time Linear dispersion viewing |
| recording mode | Continuous recording, adjustable range (3~ 60 seconds) |
| Temperature switching | ℃/° F swap |
| Display | TFT color screen 2.8 inches |
| Automatic shutdown | Yes. |
| language | Chinese/English, toggle |
| Alarm function | Upper and lower limit temperature settings |
| Calibrating function | Factory preset two-point calibrated 0 ℃, 1000 ℃ |
| External Power mode | Type-c USB（DC 5V） |
| Battery Capacity | 5000 mA/h 3.7V polymer lithium battery (built-in) 35h at full charge |
| Random with thermocouple wire | K type thermocouple wire, length 2 meters, wire temperature resistance 300 ℃, K type thermocouple wire wire precision: + -0.5%. High temperature wire greater than 300 ℃ needs to be specially selected from the manufacturer |
| Operating Temperature | -20℃～60℃ |
| Operating Humidity | 1~90%RH |
| Dimensions | 205mm*100mm*38mm |
| Encasement method | Hard box cloth bag + color box |
| Body Weight | 400 g |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41694/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
