Specifications
| Temperature Measurement Range | -200~1300℃ |
| Number of channels | 16 channels |
| meet the standard | GB/T30429-2013 |
| Thermocouple | K type |
| Accuracy | 0.2%+1℃ |
| Resolution | 0.1℃（0.1℉） |
| Accuracy | -200 degrees to 0 degrees (reading value x0.5% + 2) ℃; 0 degrees to 200 degrees (reading value x0.5% + 1.5) ℃; 201 degrees to 1300 degrees (reading value x0.5% + 2) ℃ |
| Sampling rate | 2s |
| J-type Thermocouple (optional) | -200~1200℃（-328℉~2192℉） |
| T-type Thermocouple (optional) | -200~400℃（-328℉~752℉） |
| E-type Thermocouple (optional) | -200~1000℃（-328℉~1832℉） |
| N-type Thermocouple (optional) | -200~1300℃（-328℉~2372℉） |
| Computer analysis software | optional |
| data record storage | Local storage, U disk storage |
| data record export | U disk and local connection Export/Computer and local Connectivity View Txt documentation |
| time record storage | Yes. |
| Storage Capacity | The local storage can be stored for 3.5 days without an external U disk (5-second recording interval), and the external U disk supports a maximum Capacity of 32G |
| Temperature record storage | Yes. |
| time display | Yes (year~ month~ day and hour: minute) |
| time setting | Yes. |
| Linear dispersion chart | The menu interface of this machine can be used for temperature recording and time Linear dispersion viewing |
| recording mode | Continuous recording, adjustable range (3 to 60 seconds) |
| Temperature switching | ℃/° F swap |
| Display | TFT color screen 2.8 inches |
| Automatic shutdown | Yes. |
| language settings | Chinese/English, switch |
| Alarm function | Upper and lower limit temperature settings |
| Adjustment | Factory preset two-point calibrated 0 ℃, 1000 ℃ |
| External Power Supply mode | Type-c USB（DC 5V） |
| Battery Capacity | 5000 mA/h 3.7V polymer lithium battery (built-in) 35h at full charge |
| Thermocouple cable included | K-type Thermocouple wire, length 2 meters, wire temperature resistance 300 ℃, K-type Thermocouple wire Accuracy: + -0.5%. High temperature wire greater than 300 ℃ needs to be specially selected from the manufacturer |
| Operating temperature | -20℃~60℃ |
| Operating humidity | 1~90%RH |
| Dimensions | 205mm*100mm*38mm |
| Encasement mode | Hard box cloth bag + color box |
| Airframe Weight | 400 g |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41695/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
