Specifications
| Splint Sensors | Four |
| Use Voltage | AC 220V/50Hz |
| Capacity | 2000Kg |
| Force Controller | LCD display shows maximum breaking force value, holding time, displacement |
| Sensor Accuracy | 1/20000, Measurement Accuracy 1% |
| Lifting displacement | Lifting displacement 0-120OMM/lifting displacement Accuracy according to the scale |
| Maximum allowable specimen height | 2.2 meters (plus the displacement height of 1.2 meters, the overall height of the equipment is about 2.8 meters) |
| Clamping plate size | Width 1.2 × Height 1.2 meters |
| Clamping test speed | 5-50MM/MIN (adjustable) |
| Force unit | Kgf/N/Lbf |
| Automatic stop mode | Up and down limit setting stop |
| Transmission mode | Servo motor |
| protection device | Leakage protection, travel limit device |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41701/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
