Specifications
| Measurement range | 0-500NTU, the range can be customized |
| Resolution | 0.1% |
| Repeatability | ±1.0% |
| menu | Support Chinese and English menu switching |
| control interface | Two sets of ON/OFF relay contacts, divided into high point and low point alarm signal photoelectric isolation, output |
| Signal output | 1 channel 4~ 20mA output |
| relay | The relay lag can be set arbitrarily, and the relay load is 3A 220VAC/24VDC. |
| Operating Conditions | Ambient Temperature is 0~60 ℃, Relative Humidity ≤ 90% |
| output load | Load < 500Ω (0-10mA), load < 750Ω (4-20mA) |
| Operating Voltage | 220VAC +/- 10%, 50/60Hz or book DC24V |
| Instrument size | 100x106x168mm |
| Sensors size | 380x270x80mm |
| opening size | 92×92mm |
| Weight | 0.9Kg (meter); 3.5kg (sensor) |
| protection level | IP65 (meter); IP68 (flow-through internal) |
| Accuracy | ±2%FS |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41740/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
