Specifications
| Measurement range | 250~5600kpa |
| Clamping Force | ＞690KPa |
| Display | LCD |
| unit conversion | kg、LB、Kpa |
| viewpoint size | 121*93mm |
| Upper clamp ring aperture | Φ(31.5±0.05)mm |
| Lower clamp ring aperture | Φ(31.5±0.05)mm |
| film thickness | Thickness of the convex part 2.5mm |
| Resolution | 1kpa |
| Accuracy | ±0.5%fs |
| Oil delivery speed | 170±15mL/min |
| Dimensions | 445*425*525mm |
| printout | Micro thermal printer prints test data |
| Machine Weight | 50kg |
| Power | 120W |
| Power | AC220±10%，50Hz |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41764/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
