Specifications
| Spreader thickness range | 0.01~ 10Mm drawdown blade can be lifted |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 400*400mm |
| Spreader time | Digital display, different speed, time Accuracy control, |
| Coating rod specification | Standard 1 China wire rod and 1 imported wire rod with Accuracy up to 1μm |
| Application width | 300mm |
| Drawdown blade length | 400MM material/stainless steel |
| Host Power Supply | 220V 50Hz 1700W |
| Dimensions | 626*510*520mm |
| Weight | Net Weight 55KG |
| speed control | Infinitely variable speed |
| Coating table material | Glass plate |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, Imported bar X1, Drawdown blade X1, Product manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41876/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
