Specifications
| Lighting method | D/8 (diffuse illumination, 8 ° direction reception) |
| Measurement structure | SCI/SCE includes specular reflection/excludes specular reflection; includes UV measurement/excludes UV measurement |
| Meet the standard | CIE NO.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7 |
| Measurement repeability | ΔE*ab≤0.018 |
| stand-alone difference | ΔE*ab≤0.18 |
| Display Accuracy | 0.01 |
| Measurement/Lighting Aperture *** | Five caliber: φ 8mm/φ 10mm platform + φ 8mm/φ 10mm pointed nozzle + φ 4mm/φ 5mm platform + φ 4mm/φ 5mm pointed nozzle + 1 * 3mm |
| Measurement index | Light spectrum reflectance, CIE-Lab, CIE-LCh, HunteLab, CIE-Luv, XYZ, Yxy, RGB, color difference (delta E * ab, delta E * cmc, delta E * 94, delta E * 00) |
| Light source conditions | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11,F12,CWF,U30,U35,DLF,NBF,TL83,TL84,ID50, |
| display mode | Light spectrum plots/data, sample chromatic values, color difference values/plots, pass/fail results, Color simulation, Color bias |
| lighting source | Light spectrum LED light source, UV light source |
| Measurement and positioning method | Camera viewfinder positioning, stabilizer, visual |
| Calibrating method | Intelligent auto calibration (contactless automatic lifting) |
| Accuracy | First Class Measurement Pass |
| Viewing Angle | CIE 2°/10° |
| Integrating sphere size | Φ40mm |
| spectroscopy | Plane grating spectroscopy |
| Sensor | Large area silicon photodiode array (dual row 22 groups) |
| wavelength interval | 10nm |
| Wavelength range | 400~700mm |
| Reflectance Measurement Range | 0~200% |
| Reflectance resolution | 0.01% |
| measurement mode | Single measurement, average measurement (2~ 99 times) |
| Measurement time | About 1 second |
| Dimensions | 114*70*208mm |
| Weight | Approximately 435g (excluding calibration seat) |
| battery life | Lithium battery, 3.7V, 5000mAh, 8500 cycles in 8 hours |
| Lifetime of lighting source | More than 1.50 million measurements in 10 years |
| Display | TFT true color 3.5inch, capacitive touch screen |
| interface | USB, Bluetooth ® 5.0 |
| data storage | 500 master standards, 20,000 samples (one data can include SCI/SCE at the same time); APP/PC Mass storage |
| Software Support | Windows, Android, IOS, Hongmeng, WeChat Mini Program, color scheme cloud |
| operating language | Simplified Chinese, English, Traditional Chinese |
| Operating environment | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage environment | -20~50 ℃, 0~85% RH (no condensation) |
| standard attachment | Power adapter, data cable, manual, quality management software (official website download), calibration box, protective cover, wristband, measurement caliber |
| optional accessories | Micro printer, powder test box |
| Measurement index 2 | Whiteness (ASTM E313-00, ASTM E313-73, CIE/ISO, AATCC, Hunter, Taube Berger Stensby), Yellowness (ASTM D1925, ASTM E313-00, ASTM E313-73) |
| Measurement index 3 | Blackness (My, dM), colour fastness, color fastness to change, Tint (ASTM E313-00), Color Density CMYK (A, T, E, M), Isochromatic Index Milm, Munsell, hiding power, force (dyestuff strength, tinctorial strength) |
| Light source condition 2 | ID65, LED-B1, LED-B2, LED-B3, LED-B4, LED-B5, LED-B6, LED-BH1, LED-RGB1, LED-V1, LED-V2, LED-V3, customizable light source |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
