Specifications
| Lighting method | D/8 (diffuse lighting, 8 ° direction reception), SCI/SCE (including specular light/removing specular light), in line with standards CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724-1, ASTM E1164, DIN5033 Teil7 |
| lighting source | Light spectrum LED light source |
| Integrating sphere size | F40mm |
| sensor | CMOS Dual Spectroscopic Sensors |
| Measurement Wavelength range | 400-700nm |
| Measurement caliber | Two diameter: SAV: Φ4mm/Φ5mm (platform + nozzle measurement diameter) |
| Light-containing method | Simultaneous testing of SCI/SCE |
| Color space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,s-RGB,HunterLab,βxy,DIN Lab99 |
| Color difference formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99,ΔE(Hunter) |
| Other chromaticity indicators | Light spectrum reflectance, WI (ASTM E313, CIE/ISO, AATCC, Hunter), YI (ASTM D1925, ASTM 313), monochromatic index Mt, lightfastmess, color fastness, force, occlusion, 555 hue classification, Munsell (C/2) (mobile APP implementation) |
| Observer angle | 2°/10° |
| Observation light source | D65,A,C,D50,D55,D75,F1,F2 (CWF),F3,F4,F5,F6,F7 (DLF),F8,F9,F10 (TPL5),F11 (TL84),F12 (TL83/U30),U35,NBF,ID50,ID65 |
| show | Light spectrum graphs/data, sample chromatic values, color difference values/graphs, pass/fail results, Color simulation, Color bias |
| Measurement time | About 1s |
| Sexual repeability | Chromatic value: MAV/SCI, standard deviation ΔE * ab within 0.035 (after preheating correction, the average value of 30 whiteboard measurements at intervals of 5s) Spectral reflectance: MAV/SCI, standard deviation within 0.1% (400~700nm: within 0.2%) |
| display Accuracy | 0.01 |
| Reflectance Measurement Range | 0-200% |
| Reflectance resolution | 0.01% |
| Measurement method | Single measurement, average measurement (2~ 99 times) |
| Positioning method | Stabilizer positioning |
| Whiteboard verification method | Contact automatic whiteboard verification |
| size | Length X width X height = 94X68X188mm |
| Weight | 270G (without calibration base) |
| Battery level | Lithium battery, 3.7V, 5000mAh, 8000 times in 8 hours |
| Lighting source life | More than 1.20 million measurements in 10 years |
| Display | TFT true color 2.8inch, capacitive touch screen |
| interface | USB |
| Store data | 500 master standards, 5000 samples (one piece of data can include SCI/SCE at the same time), PC Mass storage |
| Software Support | Windows |
| language | Simplified Chinese, English, Traditional Chinese |
| Operating temperature range | 0~40 ℃, 0~85% RH (no condensation), altitude: less than 2000m |
| Storage temperature range | -20~50 ℃, 0~85% RH (no condensation) |
| Standard accessories | Power adapter, data cable, manual, quality management software (official website download), black and white correction box, protective cover, wristband, measurement caliber |
| Optional accessories | Micro printer, powder test box |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
