Specifications
| Speed regulation mode | Frequency conversion speed regulation |
| Effective Volume in Reaction Kettle | 100L |
| Voltage/Frequency | 220V/50Hz |
| Rotation speed Display mode | digital display |
| Temperature Display mode | PT100 Sensors Digital Display |
| main body bracket | Stainless steel + aluminum alloy |
| mezzanine Capacity | 18L |
| Interlayer inlet and outlet circulation port | Low input and high, φ 45mm flange port matching flange, 6-point outer wire adapter |
| Number of bottle caps and bottle mouths | six |
| Discharge port off the ground | 350mm |
| Kettle reaction temperature | -80~250℃ |
| vacuum | 0.098MPa |
| Rotation speed | 0~450rpm |
| Condenser | Should be 100mmx600H (mm) with a 60mm flange |
| Constant pressure funnel | 2L 29 #standard port with Glass plug 40 #standard plug |
| Pressure relief device | 34 #standard pressure reducing valve |
| Temperature measurement port | φ 45mm flange |
| Vacuum Display mode | Vacuum meter, pointer display |
| Net Weight | 95KG |
| Product size | 95x75x239cm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41922/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
