Specifications
| Spreader Accuracy | ±0.003mm |
| Spreader thickness range | 0~10Mm drawdown blade can be lifted |
| Coating speed | 2~ 300Mm/s servo motor |
| Coating size | 300*600mm |
| Vacuum Area | 300 * 600Mm (can be customized) |
| Heating Temperature range | RT+~180℃ |
| Temperature Accuracy | ±3℃ |
| Vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Vacuum pump size | 380*180*280mm |
| Host Power Supply | 220V 50Hz |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| Optional | Leakage tank, substrate fixing fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
Packing list
Film Applicator X1, External Vacuum Pump X1, Drawdown blade X1, Product Manual X1, Opacity Chart x1 box (250 sheets)
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41941/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
