Specifications
| Number of samples processed | 24 pieces |
| Temperature range | RT+5~150℃ |
| Power | AC220V/50-60Hz |
| Power | 400W |
| Display mode | LCD LCD |
| Timer | 99h59min |
| Maximum intake pressure | 0.04MPa (≤ 16 pcs) 0.12MPa (> 16 pcs) |
| Blowing pinholing diameter | φ 2 × 150mm, inner diameter 1.3mm |
| Maximum lifting stroke | 285mm |
| Standard Metal Module Specifications | Φ16.5mm×24 孔 |
| Net Weight | 8kg |
| Product size | 330×220×540mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41968/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
