Specifications
| Number of samples processed | 12. |
| Temperature range | RT+5~150℃ |
| Power | 220V 50HZ |
| Power | 200W |
| Display mode | LED digital tube |
| Temperature control Accuracy | ≤ ±0.5℃ |
| Timer | 99h59min |
| Gas flow rate meter | 15L/min |
| Maximum intake pressure | 0.02MPa (≤ 16 pcs) 0.05MPa (> 16 pcs) |
| Blowing pinholing diameter | φ 2.4 × 150mm, inner diameter 1.6mm |
| Maximum lifting stroke | 200mm |
| Metal Module Specifications | 96×76.5mm |
| Net Weight | 7kg |
| Product size | 280×240×500mm |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41969/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
