Specifications
| Number of samples processed | 24 pieces |
| Temperature range | RT+~100℃ |
| Heating mode | Water bath heating |
| Power | 220V 50Hz |
| Power | 1000W |
| Display mode | LED digital tube |
| Temperature control Accuracy | ±1℃ |
| Temperature Uniformity | ±1℃ |
| Gas flow rate meter | 15L/min |
| Maximum intake pressure | 0.02-0.05MPa |
| Blowing pinholing diameter | φ 1.8 × (150 + 100) mm, inner diameter 1.3mm |
| Maximum lifting stroke | 150mm |
| Net Weight | 11.9kg |
| Product size | 425×320×680mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/41979/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
