Specifications
| Host structure | Integrated horizontal host frame structure |
| maximum test force | 1000N |
| Test force Measurement Range | 1%~100%Fs |
| Displacement measurement Accuracy | ≤±0.5% |
| Displacement resolution | 0.01mm |
| Test speed range | 0.1mm/min~ 100mm/min, no speed regulation |
| Speed Accuracy | ±1% |
| Maximum stretch stroke | 90mm |
| Specimen clamping range | 200×65mm |
| Dimensions | 720×370×300,, |
| Host Weight | About 45Kg |
| Power Supply | 1KW220V |
| stretch space | The host structure is a horizontal single tensile test space |
| Room temperature | 10~45℃ |
| Relative Humidity | 20%-80% |
| Levelness | 0.2/1000 |
| Power Supply fluctuation | No more than 10% of the Rated Voltage. |
| Operating Environment | No vibration around, no corrosive medium, no strong magnetic field interference |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42053/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
