Specifications
| Impact Energy - Cantilever Beam | 2.75J、5.5J |
| Impact Energy - Simply Supported Beam | 1J、2J、4J、5J |
| pre-elevation angle | 150° |
| Impact velocity | 3.5M/s, 2.9m/s or specified |
| Pendulum center distance | 335mm、230mm |
| Simply supported beam support distance | 60mm、70mm、95mm |
| Impact blade radius of cantilever beam | R=0.8±0.2mm |
| Impact blade radius of simply supported beam | R=2mm±0.5mm |
| Impact edge to upper jaw surface distance | 22mm±0.05mm |
| Impact blade angle | 30°±1° |
| Power Supply | AC220V±10% 50HZ |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42136/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
