Specifications
| Coating method | Drawdown blade |
| Effective application width | 0-25mm |
| Coating speed | 5~25m/min |
| Host Power | 220V 50Hz |
| unwinding diameter | ≤Φ400mm |
| winding diameter | ≤Φ400mm |
| Heating mode | Stainless steel electric heating tube |
| temperature control | Room temperature~ 250 ℃ +/- 3 ℃ |
| Unwinding Unit - Type | Single station |
| Unwind Unit - Effective Unwind Width | 100mm |
| Unwinding Unit - Effective Unwinding Diameter | ≤ φ 400mm (adjustable) |
| Unwinding Unit - Unwinding Scroll | Inflatable shaft |
| Unwinding Unit - Unwinding Tension Control | Tension Controller automatic control |
| Spreader Unit - Spreader Mode | Drawdown blade |
| Spreader unit - drawdown blade material | 304 stainless steel |
| Spreader unit - application width | 22mm、25mm |
| Spreader Unit - Spreader Thickness | 0-10mm |
| Spreader Unit - Spreader Adjustment | dial adjustment |
| Spreader Unit - Spreader Accuracy | ±0.02mm |
| Spreader Unit - Coating Tray | 304 stainless steel |
| Feeding melting unit - type | Resistance wire cylinder heating |
| Feed melting unit - Capacity | 1L (removable) |
| Feed melting unit - material | stainless steel |
| Feed melting unit - temperature | Room temperature~ 200 ℃ +/- 3 ℃ |
| Feed melting unit - temperature control | Digital temperature control meter automatic proportional temperature control |
| Winding Unit - Type | Single station |
| Winding Unit - Effective Winding Width | 100mm |
| Winding Unit - Effective Winding Diameter | ≤ φ 400mm (adjustable) |
| Winding Unit - Winding Reel | Inflatable shaft |
| Winding Unit - Winding Tension Control | Tension Controller automatic control |
| Air-cooled water-cooled unit - water-cooled slot size | 500*150*100mm |
| Air-cooled water-cooled units - number of air-cooled fans | 4个 220V 50HZ |
