Specifications
| Drawdown blade Accuracy | ±0.003mm |
| Drawdown blade thickness range | 0~10Mm drawdown blade can be lifted |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Mayer Rod Accuracy | ±0.001mm |
| Vacuum Area | 250*400mm |
| vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| drawdown blade | length |
| Coating rod Spreader thickness | 1-571.5 μm (Spreader thickness according to bar model) |
| Host Power Supply | 220V 50HZ |
| Dimension | 630*410*520mm |
| Weight | Net Weight 65KG |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Heating Temperature range | RT+~200℃ |
| Temperature Uniformity | ±3℃ |
| Power | 1500W |
| Vacuum pump size | 380*180*280mm |
| Feeding Capacity | Stainless steel syringe (Max: 100ml) |
| Feeding speed | 0.05-20 mm/s (barrel piston speed) |
| Bar, drawdown blade material | stainless steel |
| Feeding drum Volume | 1L |
| Heating mode | Upper + baseplate heating |
| Coating method | Bar + drawdown blade |
Packing list
Film Applicator X1, Feeding System x1, External Vacuum Pump X1, Slot-die Drawdown blade X1, Imported bar X1, Product Manual X1, Heating System x1
After-sales instructions
Warranty days: 365 days
