Specifications
| Interior Volume | 150L |
| Temperature range | -40~150℃ |
| Temperature Fluctuation | 0.5℃ |
| Humidity control range | 20~98%R.H |
| Humidity Deviation | ≤3% |
| Interior size | 500*500*600mm |
| Dimensions | 1000*1120*1500mm |
| Temperature deviation | ≤2℃ |
| Heating rate | RT +~ 150 ℃ Technologies 40min (no-load nonlinear) |
| Cooling rate | RT + → -60 ℃ Technologies 60min (no-load nonlinear) |
| Humidity stability | 3%R.H |
| Chamber material | Stainless steel plate (SUS #304) |
| Enclosure Material | Stainless steel plate atomization treatment (SUS #304) or cold plate paint (optional) |
| Insulation material | Rigid Polyurethane Foam and Glass Cotton |
| Air supply circulation system | (1) 1 90W motor; (2) Stainless steel extended shaft; (3) Multi-wing fan blade (SIRCCO FAN) |
| Box door | Single door, single window, open left, handle on the right |
| Box door window | 260X340x40mm, 3 vacuum layers |
| Compressor | French original imported fully dense compressor |
| refrigerant | Environmentally friendly refrigerant R404A |
| Condenser | Fin type with heat dissipation motor |
| Evaporator | Fin type multi-stage automatic load Capacity adjustment |
| Miscellaneous Accessories | Drying agent, Refrigerant Flow rate window, Expansion valve |
| expansion system | Capacity-controlled refrigeration system |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42198/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
