Specifications
| Combustion device | Bunsen lamp, the inner diameter of the nozzle is 9.5mm, and the length is about 100 mm. |
| Flame application time | 0~999.9 seconds ± 0.1 seconds |
| Test hole surface diameter | 102mm |
| automatic control | Automatic ignition, automatic control of test process |
| Use gas | Liquefied gas, or methane |
| Test cover width | 24 (610mm), octagon |
| Test cover height | 12″(305mm) |
| component | Including combustion and support frame, test table, standard metal mesh, standard metal mesh screen |
| Operating conditions requirements | Room temperature within the range of 10 ℃ -40 ℃; environment humidity within 30% -80% |
| other | The machine needs to be installed and positioned on a horizontal platform with a certain strength |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/42272/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
